Advanced PCB Direct Imaging &UV Exposure Machine Manufacturer Since 2011

KST Optical machines works for......

Double sided PCB,Multi Layer PCB,HDI,IC Substrate,LED Auto Light PCB

Your Professional PCB Direct Imaging And UV Exposure Machine Manufacturer in China

 KST Optical is a  back-up companies to be listed in 2022. Which is advanced in manufacture all range Auto Alignment UV exposure machine and Direct Imaging machine for Solder Mask and Outer Layer. KST Optical has two subsidiaries, Rsee Lighting And Krun, which for LED light sources And Precision Mechanical Components.

Our machines

Your professional UV exposure machine and Direct Imaging System manufacturer in China

Inner/Outer Layer

All in One Machine
Auto Alignment
DI for Patterning

Solder Mask/PSR

Single Side Solder Mask
Double Side Solder Mask
Direct Imaging for Solder Mask

Full Automatic Exposure Machine

  • New generation high speed, high precision LED Full automatic exposure system.
  • Double drawers switchover running, improve the operating efficiency, the capacity can reach to 4-4.5 pieces/minutes;
  • Both sides of working table applies the support structure of guide rails, equipped with independent high – precision lifting platform, with good stability, high repeat positioning accuracy.
Inner Layer

Capacity:

4.5-5 panel/minute

Outer Layer

Capacity:

4-4.5 panel/minute

Solder Mask

Capacity:

4-4.5 panel/minute

Our Facility and Capability

KST own its CNC machining (3-Axis, 4-Axis, 5-Axis), Milling/turning/grinding, Sheet metal fabrication (laser cutting & bending & stamping) center,  greatly ensure the processing accurancy of machines parts.

So as to ensure the PCB precision during production by using KST machines.

See KST Real Factory Online

KST Customers' Production Land

KST is selling its products around the world, with its most clients in the United States, the United Kingdom, South Korea, Philippines, India, Slovenia, Ukraine, and Vietnam. Included in the major domestic clients are TPLINK, FastPrint, Guangdong Ellington, AskPCB, TPC(Tianjin Printronics Circuit Corp.,), Aohong Electronics, Glorysky Group, Zhongfu, MLS, Beyond Sci-tech, Sihui Fuji Electronics Technology, Olympic, Kingshine Electronic Technology, Starriver Group, Fuchangfa Circuits Group, Elec & Eltek, Techwise, Camelot, etc

Quality Policy

ISO9001:2015 Certificate

Auto machine CE Certificate
Manual machine CE Certificate

Globle Installation Services

         We help more than 100 global clients installing the machines for their PCB production– over 30% of the world’s leading global brands – put customers at the center of their businesses,bring the advanced PCB production technology to improve their production speed and condition.

Exhibitions

FAQs About KST Machines

KST has been supply machines for 11 years and we have encountered all kinds of problems,here are the most important concerns of our customers before closing the deal.

What is KST machine warranty?

1 year warranty including free machine parts replacement ( consumables are not included). But LED light source with 3  Years warranty.

Can your engineer come to us for installing the machine & handle problems?

Yes,we can. And it is free-cost for the installing & training for 15 work days,you just need to pay for the air tickets & accommodation for our engineer.

How about after-sales service process?

When your machine has problem, just contact your sales and we will answer your problem within 10 minutes via working time, off work will reply in 24 hours. All the machine has teamviewer, we can connect and solved online.

Are you a trade company or manufacturer?

Yes, we are a super large manufacturer with over 11 years professional experience in China.Welcome the exclusive agents in Europe/Asia/Africa/America to join us. OEM & ODM service are available.

Do you inspect the machine before shipping out?

Yes, each step of production machine will be inspection by our QC department and the running inspection video will be sent to to you for your verification before shipping.

Does the packing strong?

Yes, of course! All of our export packing is with strong wooden case and do vacuum packing,all are confirm to export packing standard.

Do you have stock product to sell?

Normally we don’t,it depends on which models you inquired .

What is your lead time?

It usually takes 40-60 days for proceeding the production line.

Does your machine with CE certificate?

Yes.We have CE ,ISO9001,TS16949.

WANT TO KNOW MORE SPECIFIC DETAILS?

Do you need PCB UV exposure machine, Direct Imaging or PCB manufacture, or PCB assembly services? KST is one of your best choices. As one of the best PCB machines manufacturers in China, KST has passed different kinds of certifications such as ISO9001, TS16949, and UL. There’re over 100 clients who are from more than 60 countries. Contact With Experts Request For Catalog.

Get Services from our most experienced consultants

Note: Your email information will be kept strictly confidential.

Auto Alignment PCB Outer Layer Exposure Machine

Model Exposure Size Exposure Mode Exposure for Line/Space
KST-SA6254-WX 623*546 Auto Alignment Double sided Exposed at same time Dry film Wet film 50/50um
KST-SA7262-WX 723*622 Auto Alignment Double sided Exposed at same time Dry film Wet film 50/50um
KST-AEM6457-WX 623*546 Full automatic Dry film Wet film 50/50um
KST-AEM7262-WX 723*622 Full Automatic Dry film Wet film 50/50um

1) Simple structure in linear type ,easy in installation and maintation.

2) Automatic energy calibration and compensation, uniformity>85%, some above>90%

3) LED Technology, power savings, high efficiency, cost effective.

4) Built in temperature monitor module, alarming when LED over temperature.

5) High precision constant current driving power supply design, reducing the current impact of LED, greatly prolongs the LED service life

Auto Alignment Solder Mask UV Exposure Machine

Model Exposure Size Exposure Mode Exposure for Solder Dam
KST-SA6254-FH 623*546 Auto Alignment Solder Mask all colors 75/75um
KST-SA7262-FH 723*622 Auto Alignment Solder Mask all colors 75/75um
KST-SA6254-TFH 623*546 Auto Alignment Double sided Exposed at same time Solder Mask all colors 75/75um
KST-SA7262-TFH 723*622 Auto Alignment Double sided Exposed at same time Solder Mask all colors 75/75um

Features:

  1. Power module design slow current rise mode, ensure LED life.
  2. Using communication mode compensated monitoring LED brightness quality.
  3. Built-in temperature module that can monitor LED board temperature any time.
  4. LED light source modular designs that easy maintenance and replacement.
  5. Double sided machine with 8-axis independent 8-CCD auto alignment, alignment accuracy≦10μm.
  6. Automatic energy calibration and compensation, uniformity can automatic calibration to above 90%.
  7. Through multi-wavelength mixed achieves the best resolution, undercut ≦0.7mil(on copper surface).
  8. Production speed 2.5~3 pcs/min.

Professional innovation, leading technology, real-time service, timeless

Model Exposure size Exposure Mode Exposure For Resolution
KST-E7070-XL 700*700 Double Sided Dry film and Wet film L/S:50/50um
KST-E10070-XL 1060*700 Double sided Dry film and Wet film L/S:50/50um
KST-E12570-XL 1250*700 Double Sided Dry film and Wet film L/S:50/50um
KST-E15070-XL 1500*700 Double Sided Dry film and Wet film L/S:50/50um
KST-E20080-XL 2000*800 Double Sided Dry film and Wet film L/S:50/50um

LED service life: 3 years

LED Light Source

Main features:
1) Simple structure in linear typ ,easy in installation and maintation.
2) Automatic energy calibration and compensation, uniformity>85%, some above>90%
3) LED Technology, power savings, high efficiency, cost effective.
4) Built in temperature monitor module, alarming when LED over temperature.
5) High precision constant current driving power supply design, reducing the current impact of LED, greatly prolongs the LED service life.
